| Audio Integrated | YES |
| Expansion Ports | HDMI Audio jack(s) VGA DVI-D PS/2 RJ-45 USB 2.0 USB 3.0 |
| Firewire Connection | 0 |
| Graphic Card | Only if integrated in CPU |
| Highlights | 1 PCIe 3.0 x16, 2 PCIe 3.0 x1 1 SATA Express, 6 SATA3 Supports 6th Generation Intel® Core™ Processors (Socket 1151) Supports Full Spike Protection, ASRock Live Update & APP Shop 6 USB 3.0 (2 Front, 4 Rear) Supports Dual Channel DDR3 1866(OC) Supports Triple Monitor ASRock Super Alloy Graphics Output Options: D-Sub, DVI-D, HDMI 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps |
| Integrated Vga | NO |
| Internal Connector | 1 x 4 pin 12V power connector 1 x Chassis Intrusion and Speaker Header 1 x 24 pin ATX Power Connector 1 x COM Port Header 1 x Front Panel Audio Connector 1 x TPM Header 2 x USB 2.0 Headers (support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x Chassis Fan connector (4-pin) 1 x CPU Fan connector (4-pin) |
| Length (cm) | - |
| Link | http://www.asrock.com/mb/Intel/B150M-HDVD3/?cat=Specifications |
| Maximum Memory (gb) | 32 GB |
| Memory Bus | DDR3-1333 DDR3-1600 DDR3-1866(OC) DDR3-1066 |
| Memory Technology | un-buffered DDR3 DDR3L Dual channel non-ECC |
| Mini-pci Slots | 0 |
| Motherboard Chipset | Intel B150 |
| Multi Processor Support | NO |
| Nic | 10/100/1000 |
| Parallel Ports | 0 |
| Pci Express 16x | 1 |
| Pci Express 1x | 2 |
| Pci Express 4x | 0 |
| Pci Express 8x | 0 |
| Pci Slots | 0 |
| Product Description | ASROCK B150M-HDV/D3 LGA1151 mATX |
| Ps/2 Connectors | 1 |
| Raid | NO |
| Raid-controller | - |
| Sata 3 Gb/s | 0 |
| Sata 6 Gb/s | 6 |
| Sata Connectors | 6 |
| Serial-ports | 0 |
| Socket | LGA1151 |
| Speaker Support | 5 SPEAKERS |
| Supports Cpu | Supports Intel Turbo Boost 2.0 Technology Supports 6th Generation Intel Core i7/i5/i3/Pentium/Celeron Processors (Socket 1151) |
| Total Memory Slots | 2 |
| Usb 2.0 | 2 |
| Usb 3.0 | 4 |
| Usb 3.1 | 0 |
| Usb-ports | 6 |
| Width (cm) | - |
